- AB620A5035 Instruction Manual
Mode 17 (Stitchlock Pegasus)
Mark
Function
Parameter
Control
V810
V820/V850
FAm
Mode 17
Positon 2
Trimmer and Thread wiper
ON
ON
290=17
Button S5
Button S2
Button 4
Button 7
Button 5
n1
n2
n7
Positioning speed
Maximum speed
Trimming speed
110
111
116
dr°
t3
kd1
kt1
kd2
kt2
kd3
kt3
kdF
Angle dependent Stopp for trimmer
Delay from sewing foot lifting
Delay time until trimmer LFA
On periods of des Lege trimmer LFA
Delay time until Trimmer FA ON
On periods of trimmer FA
Delay of Stitchlock function STS
On periods of Stitchlock-function STS
Delay time until sewing foot On
197
202
280
281
282
283
284
285
288
