Efka AB620A5035 - Page 93

- AB620A5035 Instruction Manual
- 93 -
Parameters
Designation
Unit
Max
Min
Preset
Ind.
294 tF2
Selection of the input function using key (B) “F2” on the
V810/V820 control panel
Functions of the key as with parameter 293, but at setting 0
key F2 is disabled.
100
0
1
297 mSO
Custom signal
0 = Function Off
1 = Signal is switched on whenever the light barrier is uncovered
(Pa.131 =1) or covered (Pa 131 =0)
2 = Signal is switched on whenever the light barrier is covered
(Pa.131 =1) or uncovered (Pa 131 =0)
3 = Signal switches on from the light barrier to the seam end.
4 = Signal M11 switches on like with setting 3. However, the signal
M5 (machine running) is switched off during output M11. When
signal M11 is issued, signal M6 (machine at standstill) is also
immediately issued.
3
0
0
298 nSo
Backtack synchronization On/Off
1
0
0
299 nrS
Stitch locks speed
RPM
3000
150
400
328 ob
Changing function keys on the control panel
0 = All keys are locked
1 = All keys are released, key E + start backtack,
key + end backtack (except mode 7)
2 = All keys are released, button E affects chain suction,
button + impacts tape cutter (only in mode 7)
3 = Button E and button + no function
4 = 4 = Button E, + and – no function
5 = Button E affects soft start, button + impacts tape cutter
and wiper
6 = Button E affects soft start, button + impacts tape cutter seat
start /end
6
0
1
340 1L
Lower switching threshold of input IN1
%
100
0
30
341 1L
Upper switching threshold of input IN1
%
100
0
80
342 2L
Lower switching threshold of input IN2
%
100
0
30
343 2h
Upper switching threshold of input IN2
%
100
0
80
344 3L
Lower switching threshold of input IN3
%
100
0
30
345 3h
Upper switching threshold of input IN3
%
100
0
80
346 4L
Lower switching threshold of input IN4
%
100
0
30
347 4h
Upper switching threshold of input IN4
%
100
0
80
348 5L
Lower switching threshold of input IN5
%
100
0
30
349 5h
Upper switching threshold of input IN5
%
100
0
80
350 6L
Lower switching threshold of input IN6
%
100
0
30
351 6h
Upper switching threshold of input IN6
%
100
0
80
352 7L
Lower switching threshold of input IN7
%
100
0
30
353 7h
Upper switching threshold of input IN7
%
100
0
80
360 11L
Lower switching threshold of input LSM
%
100
0
50
361 11h
Upper switching threshold of input LSM
%
100
0
70
362 15V
Switch +5V/+15V on B18
0 = +5V
1 = +15V
1
0
0
363 Evr
Ratchet mech. Interlock on /off (F-290 = 58)
1
0
0
B
364 EWi
Ratcheting bracket mech. Interlock (F290 =58)
Degrees
100
0
10
B
365 K4S
Switching Strobel class (F-290 =56)
0 = Standard Strobel machines
1 = Class 45
2 = VEB100-7 band cutter fixture
2
0
0
B
369 FSL
Target setpoint via input PedalC with frequency (AB600A)
0 = AUS
1 = ON / PedalD =Enable
2 = ON / input function 54 = enable
2
0
0
369 FSL
370 n2
Direct input of maximum speed
RPM
F-111
F-121
Display
374 nrd
Reset speed
rpm
390
70
100
B
377 tFl
Time monitoring foot lifting
sec
250
0
0
B
395 Sti
Stitch lock on /off (F-290 = 17)
1
0
0
B
395 Sti
396 FSL
Target setpoint via input PedalC with frequency
0 = OFF
1 = ON / PedalD = Enable
2 = ON / input function 54 = Enable
2
0
0
0
