Chapter 2 Conguring from the monitor screen
●
To save log data
Procedure
1. Connect a USB storage device to the USB downstream port on the back of the monitor.
USB downstream port
2. Select “Log Display”.
2
3
4
Displays the data
storage status.
5
3. Select the date (year / month / day) of the data to save.
4. Select “Run” for “Save to USB Storage”.
Data saving starts and a “Saving” message is displayed in the display area on the right side of the screen.
When the saving complete screen is displayed, select “OK”.
5. Select “Run” for “Remove USB Storage”.
When the removing complete screen is displayed, select “OK”.
6. Remove the USB storage device.
Attention
• The following USB storage devices can be used with this product (This does not guarantee operation of the
USB storage devices given below).
- USB 2.0 standard ash drives
- Supported format: FAT32
• Do not connect multiple USB storage devices simultaneously.
