Chapter 7 Reference
●
Connection procedure (Setup of USB function)
1. Connect the monitor rst to a PC using the signal cable, and run the PC.
2. Using the USB cable, connect the downstream port of a PC compatible with USB and the monitor’s
upstream port.
The USB hub function is set up automatically upon connection of the USB cable.
3. Connect the peripheral USB device to the USB downstream port of the monitor.
USB
downstream
port
USBupstream
port
