S86A
0017 = Zone ON
0018 = Zone ON/OFF toggle
0019 = Zone audio unmute
0020 = Zone audio mute
0021 = Zone audio mute toggle
0022 = Disable loudness filter
0023 = Enable loudness filter
0024 = Loudness on/off toggle
0024 = Zone treble down (XdB steps, Z steps)
0032 = Zone treble up (XdB steps, Z steps)
0033 = Zone bass down (XdB steps, Z steps)
0034 = Zone bass up (XdB steps, Z steps)
0035 = Zone volume down (Xdb step, Y steps)
0036 = Zone volume up (Xdb step, Y steps)
0037 = Page volume down (Xdb step, Y steps)
0038 = Page volume up (Xdb step, Y steps)
0039 = Doorbell volume down (Xdb step, Y steps)
0040 = Doorbell volume up (Xdb step, Y steps)
0041 = Source level adjustment down (Xdb step, Y steps)
0042 = Source level adjustment up (Xdb step, Y steps)
0043 = Zone EQ Flat - return bass & treble to 0dB
0047 = Video Mute (based on zone IR)
0048 = Select Combined A/V Source 1
0049 = Select Combined A/V Source 2
0050 = Select Combined A/V Source 3
0051 = Select Combined A/V Source 4
0052 = Select Combined A/V Source 5
0053 = Select Combined A/V Source 6
0054 = Select Combined A/V Source 7
