S86A
KEY
Description:
These are the same commands as the S86A IR commands.
Command:
&S86,KEY,zz,abcd<cr>
Query:
N/A
Reply:
N/A
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-24
abcd:
0000 = All zones off (System OFF)
0004 = Return all zones to previous audio source (Page OFF)
0005 = Route ‘Page Aud In’ to all enabled zones (Page ON group 0)
0006 = Page on/off toggle - group 0
0007 = Return all zones to previous audio source (Doorbell OFF)
0008 = Route ‘Page Aud In’ to all zones (Doorbell ON)
0009 = Doorbell on/off toggle
0010 = Allow zone to be included in WHM & PAGE (DND OFF)
0011 = Exempt zone from WHM & PAGE (DND ON)
0012 = Do Not Disturb on/off toggle
0013 = All zones independent - no source tracking (WHM OFF)
0014 = All zones track current A/V source (WHM ON)
0015 = Whole House Music on/off toggle
0016 = Zone OFF
