Installation
Boiler transport
1. Remove the plastic strip.
2. Open the 4 upper folders, and remove the documentation
and the condense pipe.
3. Removethecartoninserts,removethecartonbox.
4. Removethe4screwsfromthebottompartoftheboilerand
fromtherollo󰀨railsonthepallet.
5. Positionandxtherollo󰀨railonthepallet,pushtheboiler
forwardalongtherollo󰀨railtotheground.
6. Movetheboilertotheconnectionortothecascaderack.
7. Remove the water and gas plastic cap, connect the condense
pipe, and follow the installation manual.
8. Whentheboilerisconnected,pushthefourbrakestoblockit.
The TRIGON L PLUS is a fully
equipped compact heating system,
whichhasbeenpre-setandtestedat
the factory.
The package dimensions for all
appliances are:
Width 750mm
Height 1200mm
Depth 800mm
Thismakesitpossibletotransport
all models in one piece through a
normal door.
Theboilercanbemovedusinga
fork-lift or pallet truck.Unpacking
instructions are printed on the
cardboardbox.Pleasefollowthe
proposed steps.
Disassembly of panelling
The appliance casing panels can
beeasilyremovedandthisis
recommended while the appliance is
beinginstalled.Thislimitsthepotential
for damage to occur.
Handling and carrying precautions:
- Wear protective clothing and gloves
to protect from any sharp edges.
- Theboilershouldbehandledwithits
pallet using a fork lifter, wheels can
beusedfornalpositioning.
Panelling should be attached and
secured with the supplied screw,
after assembly of the boiler, or after
maintenance works.
1
4x4x
4x4x
4
2
7
2x2x
5
3
A
B
C
6
