elco TRIGON L PLUS - Cascade Accessories

23
Installation
Cascade accessories
Thepipeworkheadersareavailable
in the dimension DN100 and are
connectedtooneanotherbytheange
couplings and gaskets, M12 or M16x55
bolts,springwashersandnuts.The
low loss header and the complete
installationcanthenbeconnectedtoit.
1.2.3. Low loss header
Thereare3lowlossheadersavailable:
- Low loss header for 1 TRIGON
L PLUS to max. 200kW supplied
with automatic air vent, drain valve
and pocket for temperature sensor
T10. Boiler connections are 2x 2",
installation connections are 2x 2".
ThelowlossheaderMUSTbe
connectedbetweentheboiler[s]and
the system pumps.
- Low loss header DN100 to 1000kW
- Low loss header DN100 DUO to
1600kW.
The low loss header comes standard
withadjustablefeet,automaticairvent,
drain valve, pocket for temperature
sensorT10,M12orM16x55bolts,
spring washers and nuts.
4. Pipe work header connection pipe
Connection pipes for pipe work
headersareavailableinthe
dimension DN100 in two versions, for
a connection on the LEFT or on the
RIGHT side of the cascade. They come
standardwithM16x55bolts,spring
washers, nuts and sealings.
5. Flow temperature sensor T10
Every system with 1 or more THISION
LPLUS-boilersmustbeprovidedwith
aowtemperaturesensorT10and
mustbeconnectedonthemaster
boiler(MTS1-T10).Theowsensor
mustbeplacedinthepocketofthelow
loss header.
6. Set of bends
Thelowlossheadercanbepositioned
ata90°angle.Asetofbendsmaybe
used for that purpose.
-BendssetDN100ow/return
7. Blanking anges
The ends of the pipe work headers
havetobettedwithblankinganges.
Theblankingangescomestandard
withafullycongureddelivery,
includingbolts,springwashersand
gaskets.
-BlankingangesetDN100ow/return
2 items
8. Welded-on anges
Uponrequest,welded-onangesare
availabletoconnectCH-pipelines
to the secondary side of the low loss
header and to connect the gas line.
-Welded-onangesetDN100ow/
return 2 items + DN65 gas 1 item
For complete overview on
available accessories please refer
to paragraph “TRIGON L PLUS
Cascade accessories “.
Required components that are not
suppliedbyELCO:
-Theinstallationpump;
- The condensate discharge system
-Theinstallationwaterlter;
-Airanddirtseparator;
-Hotwatersupply;
-Regulationvalve;
- Expansion vessel(s).
