elco TRIGON L PLUS - Operation; Boiler Setting and First-Time Startup

51
First time startup a boiler
Whenaboilerisactivatedthereisa
question as in the picture on the left.
After pressing OK the next menu is
shown.
Single boiler setting
When there is no cascade, select
“Single boiler”. The system will
automatically load all needed
parametersforasingleboiler;ifit
isadoubleenginetheenginewill
automatically set.
Cascade Setting
Iftheboilerispartofacascade
installation, select “Master boiler +
cascade“andconrmtheselectionby
pressing the OKbutton.Youwillthen
bepromptedtoconguretheappliance
as either a master or slave unit and
conguretheaddress.
Single Boiler
Slave boiler 2
Slave boiler 1
Master boiler + cascade
Unconfigured (actual)
Available configurations
Slave boiler 1
Slave boiler 4
Slave boiler 3
Slave boiler 2
Unconfigured (actual)
Available configurations
It’s needed to configure the device, press OK to
proceed
Slave boiler 4
Slave boiler 7
Slave boiler 6
Slave boiler 5
Slave boiler 3
Available configurations
Boiler setting
