elco TRIGON L PLUS - Page 44

44
MO2 OUTPUT (0-10V)
ECU I/O Menu display parameter
MO2_LV Multi Out PWM 2
24.7.5(CommercialBoiler);
26..32.7.5(CommercialBoiler–Slave1..7);
Function Function value
None 0
System pump modulator 1
DHW Pump modulator 2
Circulating pump modulator 3
BUF Filling pump modulator 4
boilerpowerfeedback 5
PADIN 1-2-3-4
ECU I/O Menu display parameter
PADIN1 Multi In AD 1
24.6.4(CommercialBoiler);
26..32.6.4(CommercialBoiler–Slave1..7);
PADIN2 Multi In AD 2
24.6.5(CommercialBoiler);
26..32.6.5(CommercialBoiler–Slave1..7);
PADIN3 Multi In AD 3
24.6.6(CommercialBoiler);
26..32.6.6(CommercialBoiler–Slave1..7);
PADIN4 Multi In AD 4
24.6.7(CommercialBoiler);
26..32.6.7(CommercialBoiler–Slave1..7);
Function DGTO val
None 0
Room thermostat HC1 1
Room thermostat HC2 2
Room thermostat HC3 3
0-10V Input request 4
DHW Timer Input 5
Heat generation lock 6
External consumer request 7
Gas Pressure Switch 9
CH Timer Input 10
Installation
Electrical connection
Multi function
