Elcon HiD 2000 Series - Safety Specifications

2-4
2.4 Safety Specifications
Terminal Safety Description Maximum External Parameters
HiD2025/2026
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2025SK/2026SK
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2029/2030
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
Uo = 1.2 V II C A-B
4-7 Io = 50 mA II B C-E Non energy storing apparatus connection
5-6 Po = 25 mW II A D-F-G
HiD2029SK/2030SK
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
Uo = 1.2 V II C A-B
4-7 Io = 50 mA II B C-E Non energy storing apparatus connection
5-6 Po = 25 mW II A D-F-G
HiD2031/2032
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2033/2034
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2035/2036
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2037/2038
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2061/2062
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 13.1 V II C A-B 1.97 70 520
1-4, 7-8 Io = 22 mA II B C-E 13.8 250 1860
2-3, 5-6 Po = 72 mW II A D-F-G 60 580 4300
HiD2071/2072
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 13.1 V II C A-B 1.97 70 520
7-1-4-8 Io = 22 mA II B C-E 13.8 250 1860
3-2-5-6 Po = 72 mW II A D-F-G 60 580 4300
