Elcon HiD 2000 Series - Approvals and Markings

2-5
Terminal Safety Description Maximum External Parameters
HiD2822/2824
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 13.1 V II C A-B 1.97 70 520
1-4, 2-5 Io = 22 mA II B C-E 13.8 250 1860
3-6, 7-8 Po = 72 mW II A D-F-G 60 580 4300
HiD2842/2844
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 13.1 V II C A-B 1.97 70 520
1-4, 2-5 Io = 22 mA II B C-E 13.8 250 1860
3-6, 7-8 Po = 72 mW II A D-F-G 60 580 4300
HiD2871/2872
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 3 50
7-1-4 Io = 110 mA II B C-E 0.74 11 200
6-2-5 Po = 720 mW II A D-F-G 2.51 22 400
HiD2873/2874
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 3 50
1-4 Io = 110 mA II B C-E 0.74 11 200
2-5 Po = 720 mW II A D-F-G 2.51 22 400
HiD2875/2876
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
7-1-4 Io = 93 mA II B C-E 0.74 16.5 230
6-2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2877/2878
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V II C A-B 0.097 4.1 58
1-4 Io = 93 mA II B C-E 0.74 16.5 230
2-5 Po = 610 mW II A D-F-G 2.51 33 470
HiD2881
Cenelec (groups) USA
Co (µµF)
Lo (mH)
L/R (µµH/ΩΩ)
Uo = 26.25 V
1-4 Io = 184 mA II B C-E 0.5 4.5 127
Po = 1.2 W II A D-F-G 1.9 8.5 241
2.5 Approvals and Markings
The HiD series complies with all the mandatory European standards and bears the CE marking.
AUTHORITY CERTIFICATE/FILE NO. STANDARD APPROVED FOR
CESI
EX-97.D.054
EX-97.D.055
EN 50.020
EN 50.014
[EEx ia] IIC
CSA Pending
C 22.2 No. 157
C 22.2 No. 142
CL. I, II, III;
Div 1; Gr. A to G
FM Pending
FM Cl. No. 3610 Entity
FM Cl. No. 3600
FM Cl. No. 3611
Cl. I, II, III;
Div 1; Gr. A to G
Cl. I, II, III; Div 2
SCS EX 97Y4109X BS 6941:1988 Ex N IIC T4
SAA Pending
AS 2380.1
AS 2380.7
[Ex ia] IIC
Certifications to other world wide standards are in existence or pending.
