Elcon HiD 2000 Series - Input Type Thermocouple N

9-6
9.1.6 Input type thermocouple “N”
1) Range 0 to +685 °C
2) Range 0 to +1300 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min ≅≅ 95°C, Max = 660°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅95°C )
OFF ON OFF OFF
3.6 ( ≅≅130°C )
OFF ON ON ON
5.0 ( ≅≅170°C )
OFF ON ON OFF
7.0 ( ≅≅235°C )
OFF OFF OFF ON
10.0 ( ≅≅320°C )
OFF OFF OFF OFF
13.6 ( ≅≅445°C )
OFF OFF ON ON
19.4 ( ≅≅570°C )
OFF OFF ON OFF
Zero Calibration (Max=585°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
+8
OFF OFF OFF OFF
+63
ON OFF OFF OFF
+110
OFF ON ON OFF
+155
ON ON ON OFF
+200
OFF OFF ON OFF
+245
ON OFF ON OFF
+290
OFF ON OFF ON
+330
ON ON OFF ON
+370
OFF OFF OFF ON
+410
ON OFF OFF ON
+450
OFF ON ON ON
+490
ON ON ON ON
+530
OFF OFF ON ON
+565
ON OFF ON ON
Span Calibration (Min ≅≅ 260°C, Max = 1300°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
9 ( ≅≅290°C )
ON ON OFF ON
12 ( ≅≅375°C )
ON ON OFF OFF
17 ( ≅≅505°C )
ON ON ON ON
23 ( ≅≅660°C )
ON ON ON OFF
33 ( ≅≅915°C )
ON OFF OFF ON
47 ( ≅≅1285°C )
ON OFF OFF OFF
Zero Calibration (Max=1090°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
0
OFF OFF OFF OFF
+235
ON OFF OFF OFF
+430
OFF ON ON OFF
+610
ON ON ON OFF
+765
OFF OFF ON OFF
+940
ON OFF ON OFF
+1090
OFF ON OFF ON
