Elcon HiD 2000 Series - Hid 2071;Hid 2072 Input Range Configurations; Input Type RTD Pt100 Ω

10-1
10 Appendix B
10.1 HiD 2071/HiD 2072 Input Range Configurations
10.1.1 Input type RTD Pt100 ΩΩ
1) Range -200 to +500 °C
2) Range -200 to +850 °C
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-22 chapter 5.10.
Span Calibration (Min=40°C, Max=450°C)
°C SW3-1 SW3-2 SW3-3 SW3-4
45
ON ON OFF ON
60
ON ON OFF OFF
80
ON ON ON ON
110
ON ON ON OFF
155
ON OFF OFF ON
210
ON OFF OFF OFF
290
ON OFF ON ON
390
ON OFF ON OFF
Zero Calibration (Max=220°C)
°C SW3-5 SW3-6 SW3-7 SW3-8
-190
ON OFF OFF OFF
-165
OFF ON OFF OFF
-135
ON ON OFF OFF
-105
OFF OFF ON OFF
-75
ON OFF ON OFF
-45
OFF ON ON OFF
-20
ON ON ON OFF
10
OFF OFF OFF ON
40
ON OFF OFF ON
70
OFF ON OFF ON
100
ON ON OFF ON
130
OFF OFF ON ON
160
ON OFF ON ON
190
OFF ON ON ON
220
ON ON ON ON
Span Calibration (Min=80°C, Max=850°C)
°C SW3-1 SW3-2 SW3-3 SW3-4
85
OFF ON OFF ON
110
OFF ON OFF OFF
150
OFF ON ON ON
210
OFF ON ON OFF
300
OFF OFF OFF ON
420
OFF OFF OFF OFF
580
OFF OFF ON ON
780
OFF OFF ON OFF
Zero Calibration (Max=670°C)
°C SW3-5 SW3-6 SW3-7 SW3-8
-190
ON OFF OFF OFF
-130
OFF ON OFF OFF
-70
ON ON OFF OFF
-10
OFF OFF ON OFF
50
ON OFF ON OFF
110
OFF ON ON OFF
170
ON ON ON OFF
230
OFF OFF OFF ON
290
ON OFF OFF ON
350
OFF ON OFF ON
410
ON ON OFF ON
470
OFF OFF ON ON
530
ON OFF ON ON
590
OFF ON ON ON
650
ON ON ON ON
