Elcon HiD 2000 Series - Input Type Thermocouple T

9-8
9.1.9 Input type thermocouple “T”
1) Range -85 to +400 °C
2) Range -270 to +400 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min≅≅63°C, Max=455°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅63°C )
OFF ON OFF OFF
3.6 ( ≅≅85°C )
OFF ON ON ON
5.0 ( ≅≅115°C )
OFF ON ON OFF
7.0 ( ≅≅155°C )
OFF OFF OFF ON
10.0 ( ≅≅213°C )
OFF OFF OFF OFF
13.6 ( ≅≅278°C )
OFF OFF ON ON
19.4 ( ≅≅375°C )
OFF OFF ON OFF
Zero Calibration (Max=345°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-77
OFF ON OFF OFF
-35
ON ON OFF OFF
+5
OFF OFF OFF OFF
+42
ON OFF OFF OFF
+74
OFF ON ON OFF
+105
ON ON ON OFF
+136
OFF OFF ON OFF
+166
ON OFF ON OFF
+193
OFF ON OFF ON
+221
ON ON OFF ON
+248
OFF OFF OFF ON
+275
ON OFF OFF ON
+299
OFF ON ON ON
+325
ON ON ON ON
+345
OFF OFF ON ON
Span Calibration (Min≅≅175°C, Max=670°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
9 ( ≅≅195°C )
ON ON OFF ON
12 ( ≅≅250°C )
ON ON OFF OFF
17 ( ≅≅337°C )
ON ON ON ON
23 ( ≅≅459°C )
ON ON ON OFF
28 ( ≅≅670°C )
ON OFF OFF ON
Zero Calibration (Max=270°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-270
ON ON OFF OFF
0
OFF OFF OFF OFF
+155
ON OFF OFF OFF
+270
OFF ON ON OFF
