Elcon HiD 2000 Series - Input Type Thermocouple K

9-5
9.1.5 Input type thermocouple “K”
1) Range -80 to +575 °C
2) Range -270 to +1372 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min ≅≅ 64°C, Max = 555°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅64°C )
OFF ON OFF OFF
3.6 ( ≅≅88°C )
OFF ON ON ON
5.0 ( ≅≅122°C )
OFF ON ON OFF
7.0 ( ≅≅172°C )
OFF OFF OFF ON
10.0 ( ≅≅246°C )
OFF OFF OFF OFF
13.6 ( ≅≅333°C )
OFF OFF ON ON
19.4 ( ≅≅471°C )
OFF OFF ON OFF
Zero Calibration (Max = 480°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-73
OFF ON OFF OFF
-34
ON ON OFF OFF
+5
OFF OFF OFF OFF
+42
ON OFF OFF OFF
+76
OFF ON ON OFF
+110
ON ON ON OFF
+147
OFF OFF ON OFF
+184
ON OFF ON OFF
+219
OFF ON OFF ON
+256
ON ON OFF ON
+293
OFF OFF OFF ON
+329
ON OFF OFF ON
+362
OFF ON ON ON
+398
ON ON ON ON
+433
OFF OFF ON ON
+469
ON OFF ON ON
Span Calibration (Min ≅≅ 200°C, Max = 1642°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
9 ( ≅≅222°C )
ON ON OFF ON
12 ( ≅≅295°C )
ON ON OFF OFF
17 ( ≅≅415°C )
ON ON ON ON
23 ( ≅≅555°C )
ON ON ON OFF
33 ( ≅≅795°C )
ON OFF OFF ON
47 ( ≅≅1150°C )
ON OFF OFF OFF
62 ( ≅≅1642°C )
ON OFF ON ON
Zero Calibration (Max=1145°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-270
ON ON OFF OFF
0
OFF OFF OFF OFF
+170
ON OFF OFF OFF
+345
OFF ON ON OFF
+510
ON ON ON OFF
+650
OFF OFF ON OFF
+820
ON OFF ON OFF
+990
OFF ON OFF ON
+1145
ON ON OFF ON
