Elcon HiD 2000 Series - Hid 2061;Hid 2062 Input Range Configurations; Input Type MV

9-1
9 Appendix A
9.1 HiD 2061/HiD 2062 Input Range Configurations
9.1.1 Input type “mV”
1) Range: -0.5 to +27 mV
2) Range: -13 to +110 mV
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min=2.6 mV, Max=23mV)
Range (mV) SW2-1 SW2-2 SW2-3 SW2-4
2.6
OFF ON OFF OFF
3.6
OFF ON ON ON
5.0
OFF ON ON OFF
7.0
OFF OFF OFF ON
10.0
OFF OFF OFF OFF
13.6
OFF OFF ON ON
19.4
OFF OFF ON OFF
Zero Calibration (Max=22mV)
Range (mV) SW2-5 SW2-6 SW2-7 SW2-8
-0.3
OFF ON OFF OFF
+1.2
ON ON OFF OFF
+2.7
OFF OFF OFF OFF
+4.1
ON OFF OFF OFF
+5.6
OFF ON ON OFF
+7.1
ON ON ON OFF
+8.6
OFF OFF ON OFF
+10.0
ON OFF ON OFF
+11.5
OFF ON OFF ON
+13.0
ON ON OFF ON
+14.5
OFF OFF OFF ON
+15.9
ON OFF OFF ON
+17.4
OFF ON ON ON
+18.9
ON ON ON ON
+20.4
OFF OFF ON ON
+21.8
ON OFF ON ON
Span Calibration (Min=8mV, Max=100mV)
Range (mV) SW2-1 SW2-2 SW2-3 SW2-4
9
ON ON OFF ON
12
ON ON OFF OFF
17
ON ON ON ON
23
ON ON ON OFF
33
ON OFF OFF ON
47
ON OFF OFF OFF
63
ON OFF ON ON
90
ON OFF ON OFF
Zero Calibration (Max=92mV)
Range (mV) SW2-5 SW2-6 SW2-7 SW2-8
-10
OFF ON OFF OFF
-4
ON ON OFF OFF
+3
OFF OFF OFF OFF
+10
ON OFF OFF OFF
+17
OFF ON ON OFF
+23
ON ON ON OFF
+30
OFF OFF ON OFF
+37
ON OFF ON OFF
+44
OFF ON OFF ON
+50
ON ON OFF ON
+57
OFF OFF OFF ON
+64
ON OFF OFF ON
+71
OFF ON ON ON
+77
ON ON ON ON
+84
OFF OFF ON ON
+91
ON OFF ON ON
