2.7.9 HiD 2061/2062 Temperature Converter, mV/TC
DC supply
Current consumption 30 mA @ 24 V, 20 mA output (per channel)
Power dissipation 0.6 W @ 24 V (per channel)
Hazardous Area Signal (Input)
User selectable input mV or TC TC type B, E, J, K, N, R, S, T to IEC 584-1
and L (GOST)
Range -10 to +100 mV
Span limits
2.6 min to 100 mV max
Zero suppression
± 500 % of span
Safe Area Signal (Output)
User selectable 4-20 mA or 1-5 V
1-5 V on 250 Ω internal shunt
Ripple content 10 mVrms
Load
0 to 650 Ω
Load effect
≤ 0.1 %
of full scale from 0 to 650 Ω
Burnout
User programmable upscale, downscale burnout current 25 nA
Performance at Reference Conditions
Calibration accuracy
< ± 0.1 %
of full scale (Current output)
Linearity
< ± 0.1 %
of full scale (terminal based mV in to mA out for TC)
Temperature drift
< ± 0.01 %/°C
Compensation error
±0.5°C ±0.05°C/°C
deviation from reference temperature for TC
Selector switches Output 4-20 mA or
1-5 V
Thermocouple type
Burnout up/down
Input zero and span
coarse settings
(250 Ω, 0.1 % internal shunt)
Factory set as 4-20 mA
TC type K
0-500 °C
upscale burn-out
Front panel adjustment
Zero and span trimmers
for each channel
LED Indicators Power ON Green
