9.1.10 Input type thermocouple “L”
1) Range -45 to +300 °C
2) Range -200 to +800 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min ≅≅ 40°C, Max=300°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅40°C )
OFF ON OFF OFF
3.6 ( ≅≅55°C )
OFF ON ON ON
5.0 ( ≅≅75°C )
OFF ON ON OFF
7.0 ( ≅≅100°C )
OFF OFF OFF ON
10.0 ( ≅≅140°C )
OFF OFF OFF OFF
13.6 ( ≅≅185°C )
OFF OFF ON ON
19.4 ( ≅≅260°C )
OFF OFF ON OFF
Zero Calibration (Max=250°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-45
OFF ON OFF OFF
-20
ON ON OFF OFF
+0
OFF OFF OFF OFF
+25
ON OFF OFF OFF
+47
OFF ON ON OFF
+68
ON ON ON OFF
+88
OFF OFF ON OFF
+100
ON OFF ON OFF
+125
OFF ON OFF ON
+145
ON ON OFF ON
+160
OFF OFF OFF ON
+180
ON OFF OFF ON
+195
OFF ON ON ON
+210
ON ON ON ON
+230
OFF OFF ON ON
+250
ON OFF ON ON
Span Calibration (Min≅≅120°C, Max=900°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
9 ( ≅≅130°C )
ON ON OFF ON
12 ( ≅≅170°C )
ON ON OFF OFF
17 ( ≅≅230°C )
ON ON ON ON
23 ( ≅≅300°C )
ON ON ON OFF
33 ( ≅≅420°C )
ON OFF OFF ON
47 ( ≅≅575°C )
ON OFF OFF OFF
63 ( ≅≅760°C )
ON OFF ON ON
Zero Calibration (Max=650°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-140
ON ON OFF OFF
0
OFF OFF OFF OFF
+100
ON OFF OFF OFF
+195
OFF ON ON OFF
+280
ON ON ON OFF
+350
OFF OFF ON OFF
+430
ON OFF ON OFF
+510
OFF ON OFF ON
+580
ON ON OFF ON
+660
OFF OFF OFF ON
