Elcon HiD 2000 Series - Input Type Thermocouple J

9-4
9.1.4 Input type thermocouple “J”
1) Range -60 to +435 °C
2) Range -210 to +1200 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min≅≅50°C, Max=420°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅50 )
OFF ON OFF OFF
3.6 ( ≅≅69 )
OFF ON ON ON
5.0 ( ≅≅95 )
OFF ON ON OFF
7.0 ( ≅≅132 )
OFF OFF OFF ON
10.0 ( ≅≅185 )
OFF OFF OFF OFF
13.6 ( ≅≅250 )
OFF OFF ON ON
19.4 ( ≅≅355 )
OFF OFF ON OFF
Zero Calibration (Max=365°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-55
OFF ON OFF OFF
-26
ON ON OFF OFF
+4
OFF OFF OFF OFF
+33
ON OFF OFF OFF
+60
OFF ON ON OFF
+86
ON ON ON OFF
+113
OFF OFF ON OFF
+141
ON OFF ON OFF
+166
OFF ON OFF ON
+193
ON ON OFF ON
+220
OFF OFF OFF ON
+247
ON OFF OFF ON
+273
OFF ON ON ON
+300
ON ON ON ON
+327
OFF OFF ON ON
+354
ON OFF ON ON
Span Calibration (Min=150°C, Max=1410°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
9 ( ≅≅170°C )
ON ON OFF ON
12 ( ≅≅220°C )
ON ON OFF OFF
17 ( ≅≅310°C )
ON ON ON ON
23 ( ≅≅420°C )
ON ON ON OFF
33 ( ≅≅600°C )
ON OFF OFF ON
47 ( ≅≅825°C )
ON OFF OFF OFF
63 ( ≅≅1085°C )
ON OFF ON ON
78 ( ≅≅1410°C )
ON OFF ON OFF
Zero Calibration (Max=1025°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-165
ON ON OFF OFF
0
OFF OFF OFF OFF
+130
ON OFF OFF OFF
+260
OFF ON ON OFF
+385
ON ON ON OFF
+495
OFF OFF ON OFF
+615
ON OFF ON OFF
+730
OFF ON OFF ON
+840
ON ON OFF ON
+935
OFF OFF OFF ON
+1025
ON OFF OFF ON
