Elcon HiD 2000 Series - Input Type Thermocouple R; Input Type Thermocouple S

9-7
9.1.7 Input type thermocouple “R”
1) Range -50 to +1768 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
9.1.8 Input type thermocouple “S”
1) Range -50 to +1768 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min≅≅320°C, Max=1818°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅320°C )
OFF ON OFF OFF
3.6 ( ≅≅420°C )
OFF ON ON ON
5.0 ( ≅≅550°C )
OFF ON ON OFF
7.0 ( ≅≅720°C )
OFF OFF OFF ON
10.0 ( ≅≅960°C )
OFF OFF OFF OFF
13.6 ( ≅≅1225°C )
OFF OFF ON ON
19.4 ( ≅≅1640°C )
OFF OFF ON OFF
Zero Calibration (Max=1515°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
+35
OFF OFF OFF OFF
+225
ON OFF OFF OFF
+370
OFF ON ON OFF
+505
ON ON ON OFF
+635
OFF OFF ON OFF
+765
ON OFF ON OFF
+875
OFF ON OFF ON
+990
ON ON OFF ON
+1105
OFF OFF OFF ON
+1215
ON OFF OFF ON
+1315
OFF ON ON ON
+1420
ON ON ON ON
+1515
OFF OFF ON ON
Span Calibration (Min≅≅330°C, Max=1818°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅330°C )
OFF ON OFF OFF
3.6 ( ≅≅435°C )
OFF ON ON ON
5.0 ( ≅≅575°C )
OFF ON ON OFF
7.0 ( ≅≅770°C )
OFF OFF OFF ON
10.0 ( ≅≅1035°C )
OFF OFF OFF OFF
13.6 ( ≅≅1335°C )
OFF OFF ON ON
19.0 ( ≅≅1818°C )
OFF OFF ON OFF
Zero Calibration (Max=1500°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
+35
OFF OFF OFF OFF
+230
ON OFF OFF OFF
+385
OFF ON ON OFF
+525
ON ON ON OFF
+675
OFF OFF ON OFF
+816
ON OFF ON OFF
+940
OFF ON OFF ON
+1070
ON ON OFF ON
+1195
OFF OFF OFF ON
+1320
ON OFF OFF ON
+1435
OFF ON ON ON
+1500
ON ON ON ON
