9.1.3 Input type thermocouple “E”
1) Range -50 to +335 °C
2) Range -270 to +1000 °C
N.B. The Thermocouple is not linearized. The Span value in °C is an average value.
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min ≅≅ 43°C, Max=325°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅43°C )
OFF ON OFF OFF
3.6 ( ≅≅59°C )
OFF ON ON ON
5.0 ( ≅≅80°C )
OFF ON ON OFF
7.0 ( ≅≅110°C )
OFF OFF OFF ON
10.0 ( ≅≅153°C )
OFF OFF OFF OFF
13.6 ( ≅≅202°C )
OFF OFF ON ON
19.4 ( ≅≅279°C )
OFF OFF ON OFF
Zero Calibration (Max=285°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-48
OFF ON OFF OFF
-23
ON ON OFF OFF
+3
OFF OFF OFF OFF
+28
ON OFF OFF OFF
+51
OFF ON ON OFF
+73
ON ON ON OFF
+95
OFF OFF ON OFF
+117
ON OFF ON OFF
+137
OFF ON OFF ON
+159
ON ON OFF ON
+179
OFF OFF OFF ON
+200
ON OFF OFF ON
+219
OFF ON ON ON
+238
ON ON ON ON
+258
OFF OFF ON ON
+278
ON OFF ON ON
Span Calibration (Min≅≅125°C, Max=1270°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
9 ( ≅≅140°C )
ON ON OFF ON
12 ( ≅≅180°C )
ON ON OFF OFF
17 ( ≅≅250°C )
ON ON ON ON
23 ( ≅≅325°C )
ON ON ON OFF
33 ( ≅≅450°C )
ON OFF OFF ON
47 ( ≅≅625°C )
ON OFF OFF OFF
63 ( ≅≅825°C )
ON OFF ON ON
87 ( ≅≅1270°C )
ON OFF ON OFF
Zero Calibration (Max=830°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
-145
ON ON OFF OFF
0
OFF OFF OFF OFF
+110
ON OFF OFF OFF
+210
OFF ON ON OFF
+300
ON ON ON OFF
+375
OFF OFF ON OFF
+460
ON OFF ON OFF
+550
OFF ON OFF ON
+630
ON ON OFF ON
+710
OFF OFF OFF ON
+800
ON OFF OFF ON
