9.1.2 Input type thermocouple “B”
1) Range 0 to +1820 °C
N.B. •• The Thermocouple is not linearized. The Span value in °C is an average value.
•• The input terminals are as for mV input:
1+ and 8- for channel 1
2+ and 6- for channel 2
Note: for all the informations regarding the configurations of the input, output and burn-out options of this
product, please refer to the procedures and tables described at page 5-19 chapter 5.9.
Span Calibration (Min≅≅270°C, Max=1820°C)
mV ( °C ) SW2-1 SW2-2 SW2-3 SW2-4
2.6 ( ≅≅270°C )
OFF ON OFF OFF
3.6 ( ≅≅380°C )
OFF ON ON ON
5.0 ( ≅≅550°C )
OFF ON ON OFF
7.0 ( ≅≅770°C )
OFF OFF OFF ON
10.0 ( ≅≅1110°C )
OFF OFF OFF OFF
13.6 ( ≅≅1800°C )
OFF OFF ON ON
Zero Calibration (Max=1600°C)
°C SW2-5 SW2-6 SW2-7 SW2-8
0
OFF ON OFF OFF
500
ON ON OFF OFF
750
OFF OFF OFF OFF
920
ON OFF OFF OFF
1090
OFF ON ON OFF
1250
ON ON ON OFF
1370
OFF OFF ON OFF
1500
ON OFF ON OFF
1600
OFF ON OFF ON
