Eldes EPIR3 - Page 10

10
10 EN
EPIR3 User Manual v1.3
height X1 X2
2,5m
(8.20ft)
3,5m
(11.48ft)
11m
(36.09ft)
2,3m
(7.55ft)
3m
(9.84ft)
11m
(36.09ft)
2,1m
(6.89ft)
1,5m
(4.92ft)
11m
(36.09ft)
1,5m
(4.92ft)
0m
(0ft)
11m
(36.09ft)
angle 0º
Height
Secured area
Maximum detection distance, X2
angle - 10º
Secured area
angle - 20º
Secured areaBlind area, X1
Height Height
Blind area, X1
Blind area, X1
Maximum detection distance, X2
Maximum detection distance, X2
17
height X1 X2
2,5m
(8.20ft)
2,5m
(8.20ft)
10m
(32.81ft)
2,3m
(7.55ft)
2,5m
(8.20ft)
8m
(26.25ft)
2,1m
(6.89ft)
1,5m
(4.92ft)
8m
(26.25ft)
1,5m
(4.92ft)
0m
(0ft)
4,5m
(14.76ft)
angle 0º
Height
Secured area
Maximum detection distance, X2
angle - 10º
Secured area
angle - 20º
Secured areaBlind area, X1
Height
Height
Blind area, X1
Blind area, X1
Maximum detection distance, X2
Maximum detection distance, X2
18
QUICK START GUIDE
