height X1 X2
2,5m
(8.20ft)
2m
(6.56ft)
5m
(16.4ft)
2,3m
(7.55ft)
1,5m
(4.92ft)
4.5m
(14.76ft)
2,1m
(6.89ft)
1m
(3.28ft)
4.5m
(14.76ft)
1,5m
(4.92ft)
0m
(0ft)
3m
(9.84ft)
angle 0º
Height
Secured area
Maximum detection distance, X2
angle - 10º
Secured area
angle - 20º
Secured areaBlind area, X1
Height
Height
Blind area, X1Blind area, X1
Maximum detection distance, X2
Maximum detection distance, X2
19
20
After a suitable location for
your EPIR3 is chosen, x the
holder to the wall using the
screws supplied.
