EPIR3 User Manual v1.3
7.11.2.1. GPRS Network
The system supports data transmission to the monitoring station via IP-based networks by GPRS network. The
supported data formats are the following:
• EGR100
• Kronos
To set up the system for data transmission via GPRS network, please follow the basic conguration steps:
1. Enable MS Mode parameter (see 7.11. Monitoring Station).
2. Set 4-digit Account number (see 7.11. Monitoring Station).
3. Set server IP address, which is a public IP address of the machine running EGR100 or Kronos
monitoring station software.
4. Set server port, which is a port of the machine running EGR100 or Kronos monitoring
station software.
5. Select TCP or UDP protocol. UDP is highly recommended for EGR100 data format.
6. Select data format: EGR100 or Kronos
7. In case EGR100 is selected, set 4-digit Unit ID number. Unit ID number can be identical
to Account number.
8. Set up APN, user name and password provided by the GSM operator. Depending on the
GSM operator, only APN might be required to set up.
By default, if the initial attempt to transmit data to the monitoring station via GPRS network
method is unsuccessful, the system will make up to 2 additional attempts. If all attempts are
unsuccessful, the system will switch to next backup connection that follows in the sequence
and will attempt to transmit data until it is successfully delivered to the monitoring station.
To report the online status, the system periodically transmits (By default – every 180
seconds) Test Event data message (ping) to the monitoring station via GPRS network
For detailed step-by-step instructions on how to establish the communication between EPIR3 alarm system and
EGR100 middleware, please refer to the middleware’s HELP le.
ATTENTION: It is necessary to restart the system locally by powering down and powering up the system the
system or remotely (see section 4. HOW TO PROGRAM THE SYSTEM USING YOUR MOBILE PHONE) after
changing the IP address or switching from TCP to UDP.
NOTE: The system is fully compatible with Kronos NET/Kronos LT monitoring station software for com-
munication via GPRS network. When using a dierent monitoring station software, EGR100 middleware is
required. EGR100 is freeware and can be downloaded at www.eldes.lt/ en/download
NOTE: Kronos NET/Kronos LT software communicates via TCP protocol, while EGR100 middle-ware v1.2 and
up supports both – TCP and UDP protocols. However, TCP protocol is NOT recommend to use with EGR100.
7.11.2.2. Voice Calls and SMS
The system supports up to 3 monitoring station phone numbers for communication with the alarm system by
Voice Calls or SMS communication method using Ademco Contact ID or Cortex SMS data format respectively.
Tel. Number 1 is mandatory, the other two can be used as backup phone numbers and are not necessary. The
supported phone number formats are the following:
• International (with plus) – The phone numbers must be entered starting with plus and an international
country code in the following format: +[international code][area code][local number], example for UK:
+441709111XXXX . This format can be used when setting up the phone number by ELDES Conguration Tool
software.
• International (with 00) – The phone numbers must be entered starting with 00 and an international
country code in the following format: 00[international code][area code][local number], example for UK:
00441709111XXXX. This format can be used when setting up the phone number by EKB3W keypad.
• Local – The phone numbers must be entered starting with an area code in the following format: [area code]
[local number], example for UK: 01709111XXXX. This format can be used when setting up the phone number
by EKB3W keypad and ELDES Conguration Tool software.
To set up the system for data transmission via Voice Calls or SMS, please follow the basic conguration steps:
1. Enable MS Mode parameter (see 7.11. Monitoring Station).
2. Set 4-digit Account number (see 7.11. Monitoring Station).
3. Set Tel. Number 1... 3.
