Eldes EPIR3 - Page 55

55
55EN
EPIR3 User Manual v1.3
Monitoring Station Settings
Function Command Value Range / Comment Example
Set server IP
address
XXXX_
SETGPRS:IP:add.add.
add.add
ADD.ADD.ADD.ADD = server IP
address.
Public IP address of the machine
running EGR100 or Kronos
monitoring station software.
1111_
SETGPRS:IP:65.82.110.15
Set server port
number
XXXX_
SETGPRS:PORT:port
port = port number, 1... 65535].
Forwarded port of the machine
running EGR100 or Kronos
monitoring station software.
1111_SETGPRS:PORT:5521
Select protocol XXXX_SETGPRS:PRO-
TOCOL:PPP
PPP = protocol, [TCP... UDP]
TCP or UDP protocol. UDP is highly
recommended for EGR100 data
format.
1111_
SETGPRS:PROTOCOL:UDP
Set APN XXXX_
SETGPRS:APN:ACCPN
ACCPN = access-point-name.
Access-point-name of GPRS param-
eters provided by the GSM operator.
1111_SETGPRS:APN:internet
Set user name XXXX_
SETGPRS:USER:USR
USR = user name.
User name of GPRS parameters
provided by the GSM operator. De-
pending on the GSM operator, only
APN might be required to set up.
1111_SETGPRS:USER:int-user
Set password XXXX_
SETGPRS:PSW:PASS
PASS = password
Password of GPRS parameters
provided by the GSM operator. De-
pending on the GSM operator, only
APN might be required to set up.
1111_SETGPRS:PSW:int-pass
NOTE: The underscore symbol ‘_’ in these instructions represents a space. So when typing an SMS text
message, replace the underscore symbol with a single space.
