Appendix B: Transmitter Installation
iConnect Installation Manual
95
Select an appropriate installation height from Table B1.
Pet Immunity Guidelines (EL-2600PI/EL-2645PI)
It is expected that the EL-2600PI and EL-2645PI will eliminate false alarms caused by:
Animals up to 22kg/48lb (EL-2600PI)
Animals up to 45kg/100lb (EL-2645PI)
Several small rodents
Random flying birds
Note: The weight of the animal should only be used as a guide, other factors such as the length and color of
fur also affect the level of immunity.
For maximum pet immunity the following guidelines are recommended:
Mount the center of the unit at a height of 2m (6.5') with the PCB vertical setting at -4.
Set the pulse counter to 2.
Do not aim the detector at stairways that can be climbed by an animal.
Avoid a location where an animal can come within 1.8m (6') of the detector by climbing on furniture, boxes or
other objects.
Lens Mounting Height
Standard 2.2m (6.6’)
Long Range 2m (6.5’)
Curtain 1m (3.25’)
EL-2600PI 2m (6.5’)
EL-2645PI 2m (6.5’)
Table B- 3: Recommended Mounting Height
Installation Procedure
To install PIR sensors:
1. Open the housing by removing the front cover. To do so, insert a screwdriver in the release slot
(located at the bottom of the detector between the front and back cover). Turn the screwdriver 90º to
release the cover.
2. Remove the PCB by turning counter-clockwise and removing the Easy Lock – do not touch the face of the pyro
sensor!
3. Apply battery power by removing the isolator that separates the battery from the contacts on the
battery holder.
4. Place the Mode jumper over pins 2 & 3 (Radio Mode); the LED flashes.
Note: Install the Mode jumper only after applying battery power. Due to the occurrence of voltage delay in
lithium batteries that have been in storage, the batteries may initially appear to be dead. In this case,
leave the unit in Test mode for a few minutes until the battery voltage level is stabilized.
5. From the Programming menu, select Devices, Zones [911].
6. Select the zone to which you want to register the transmitter; the system initiates Registration mode.
When Save? appears on the Control System’s LCD display, press .
7. Remove the Mode jumper and place it over one pin for storage.
8. Choose an appropriate mounting height from Table B.1 and test the transmitter from the exact
mounting position before permanently mounting the unit.
9. Knock out the mounting holes and attach the base to the wall.
10. Mount the PCB at the required vertical adjustment and replace the PCB screw.
11. Write the number of the zone on the sticker provided. Affix the sticker inside the front cover for future
reference and replace the front cover.
