9.7. PGM Output Options
The PGM is a programmable output that is triggered according to specific system status conditions, or by remote
command sent via PSTN, GSM, keyfob, keypad, or RP.
9.7.1. Output Trigger
The Output Trigger option determines the conditions that activate and deactivate the PGM output.
To program the Output Trigger:
1. From the Programming menu, select System Options, PGM Options, Output Trigger [94071].
2. Select an Output Trigger option from the following table.
Trigger
Option
Activated by… Deactivated by…
PGM Not
Used
The PGM output is disabled
Full Arm System "Full" armed
Perimeter
Arm
System "Perimeter" armed
Part Arm System "Part" armed
Arm Status Any arming method
System disarmed or PGM Cut-off
Power
Trouble
AC Loss or Low Battery conditions AC restore or Battery restore
Tel. Line
Trouble
Telephone line supervision trouble Telephone line restore
System
Trouble
System trouble condition System trouble restore
Medical Medical alarm
Burglary Burglary alarm
Fire Alarm Fire alarm
Any arming method, system disarmed or
PGM Cut-off
Zone
Status
*
Open zones (steady)
Bypassed zones (pulsing)
All zones closed and no zones bypassed
Entry/Exit Entry/Exit delay follower
Siren Built-in siren follower
WL Siren Wireless siren follower
WL T Siren Wireless siren SR200R follower
Telecontrol Remote PGM activation (PSTN/GSM/keyfob/keypad/RP)
Table 9-1: PGM Output Trigger Options
Note: For certain trigger options, deactivation may be determined by the PGM Cut-off -- see p. 60, 9.7.4 PGM
Cut-off. If the PGM Cut-off is programmed as 000 (continuous activation), the PGM output shall
remain activated until it is toggled by the relevant change in system status.
9.7.2. Output Type
The Output Type option determines whether the PGM output produces a steady or pulsed output.
To program the Output Type:
1. From the Programming menu, select System Options, PGM Options, Output Type [94072].
2. Select Steady or Pulsed.
Note: The Zone Status, Siren and WL Siren trigger options have a fixed Output Type; there is no need to
program an Output Type for these options.
*
Zone Status functions only when the system is disarmed.
