Appendix B: Transmitter Installation
iConnect Installation Manual
117
Transmitter Specifications
The technical specifications for the transmitters that appear in this appendix are listed below. All transmitters are
available in 868.35, or 433.92MHz (optional) FM frequencies.
EL-2600 PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission) 6µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 46 x 46ft (14 x 14m)
Pulse Count: 1, 2 or 3 Jumper Selectable
LED Indicator: Jumper Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2600PI PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission), 6µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 39.3 x 39.9ft (12 x 12m)
Pulse Count: 1, 2 or 3 Jumper Selectable
LED Indicator: Jumper Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2645 PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission) 12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 46 x 46ft (14 x 14m)
Pulse Count: 1, 2, 3 or Adaptive
LED Indicator: Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2645PI PIR
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 30mA (transmission), 12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 39.3 x 39.9ft (12 x 12m)
Pulse Count: 1, 2, 3 or Adaptive
LED Indicator: Selectable
Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: 14 to 140°F (-10 to 60°C)
Fire Protection: ABS Plastic Housing
Dimensions: 4.33"H x 2.36"W x 1.77"D (110 x 60 x 45mm)
EL-2745 PIR
Antenna: Built-in Internal Whip
Frequency: 868.35MHz*, 433.92MHz, or 418 MHz
Power: 3.6V ½ AA Lithium Battery
Caution: Fire, explosion and severe burn hazard! Do not
recharge, disassemble or heat above 100°C (212F).
Current Consumption: 30mA (transmission) 12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 14 x 14m
Pulse Count: 1, 2, 3 or Adaptive (selectable)
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: -10 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
Screw recommended: ST 2.9x22 DIN 7981 (ISO 7049)
* Complies with EN-50131 2-2 Grade 2
Class II, Power Supply Type C
EL-2745PI PIR
Antenna: Built-in Internal Whip
Frequency: 868.35MHz*, 433.92MHz, or 418 MHz
Power: 3.6V ½ AA Lithium Battery
Caution: Fire, explosion and severe burn hazard! Do not
recharge, disassemble or heat above 100°C (212F).
Current Consumption: 30mA (transmission)/12µA (standby)
Pyroelectric Sensor: Dual Element
Maximum Coverage: 12 x 12m
Pulse Count: 1, 2, 3 or Adaptive (selectable)
LED Indicator: Selectable
Digital Adaptive Temperature Compensation
RFI Immunity: 30V/m
Operating Temperature: -10 to 60°C
Fire Protection: ABS Plastic Housing
Dimensions: 110 x 62 x 50mm
Screw recommended: ST 2.9x22 DIN 7981 (ISO 7049)
* Complies with EN-50131 2-2 Grade 2
Class II, Power Supply Type C
EL-2601 Magnetic Contact/EL-2602 Universal
Transmitter
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 25mA (transmission) 10µA (standby)
Loop Input Voltage Range for EL-2602: 0-15VDC/AC (peak to peak)
RFI Immunity: 40V/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 2.5"H x 1.18"W x 0.9"D (65 x 30 x 25mm)
EL-2603 Smoke Detector
Antenna: Built-in Internal Whip
Current Consumption: 30mA (transmission), 20µA (standby)
Power: 9V Alkaline Battery
RFI Immunity: 40V/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 5.43"H x 4.65"W x 1.73"D (138 x 118 x 44mm)
EL-2603EN Smoke Detector
Antenna: Built-in Internal Whip
Frequency: 868.35MHz FM
Power: 9V Alkaline Battery
Current Consumption: 27mA (transmission) 10
μA (standby)
Humidity Range: 15%-95% RH (non-condensing)
LED Indication: Power, Trouble and Alarm (Red) RF
transmission (Blue)
Alarm: 85dB @ 3m
RFI Immunity: 10V/m
Operating Temperature: 0-55°C
EL-2606 Glassbreak Sensor
Antenna: Built-in Whip
Power: 3.6V ½ AA Lithium Battery
Current Consumption: 25mA (transmission)
30µA (standby)
Warning: Fire, explosion and severe burn hazard! Do not
recharge, disassemble or heat above 100°C (212 °F).
Microphone: Omni-directional electret
Maximum Range: 6m (plate, tempered, laminated and
wired glass)
3.65m (armor-coated glass)
RFI Immunity: 20V/m
Operating Temperature: 32 to 122°F (0 to 50°C)
Dimensions: 3.14"H x 4.25"W x 1.69"D (80 x 108 x 43mm)
EL- 2661 Flood Sensor
Antenna: Built-in Internal Whip
Frequency: 868.35, 433.92 or 418MHz FM
Power: 3.6V ½ AA Lithium Battery BT5055
