3 Basic System Operation
iConnect Installation Manual
20
3.6. System Status LEDs (LED Top Cover)
The System Status LEDs show System Troubles, Open Zone condition, and Power Status.
OK LED Status
(green)
Meaning
Off System cannot be armed.
Green On The system is ready for arming.
Flashing Open Zone. Check that the relevant entrances are secured (i.e. e. windows and doors are
closed and no movement is detected by the sensors within the protected area).
Table 3-7: Armed LED Indication
! LED Status
(yellow)
Meaning
Off System Power Status is OK and there is no trouble condition.
Yellow On System Trouble.
Yellow Flashing
(slow)
Backup battery low or low battery from transmitters.
Yellow Flashing
(fast)
AC loss.
Yellow Intermittent
On/Off
System Trouble in addition to AC loss/Low Battery.
Table 3-8: Power LED Indication
Note: Alarm indication is not displayed after a silent panic alarm.
3.7. Arming Status LEDs (LED Top Cover)
In unpartitioned systems, meaning of the three arming Status LEDs is: Full, Part, and Perimeter. In partitioned systems,
meaning of the three arming Status LEDs is: Full, Partition 1, and Partition 2 respectively.
Arming LED
Status
Meaning
Off The corresponding arming method is not active. In partitioned systems, the
corresponding partition is disarmed. If all the three LEDs are off, the system is disarmed.
Red Flashing The exit or entry delay is counting down for this arming mode.
Green On The System is armed using the arming method shown by this LED. In partitioned
systems, the corresponding partition/whole system is armed.
All the three Arm
Status LEDs are
flashing red
An alarm has occurred. Alarm indication is cleared the next time that an arming
sequence is initiated.
Table 3-9: Arm Status LED Indication
3.8. Front Panel Keypad (LED Top Cover)
The LED Top Cover keypad is used to activate the three basic end user functions listed in the following table. If your
Control system is configured with an LED Top Cover, use a hardwire LCD keypad to perform any function that
requires keypad/ LCD interface.
