Appendix B: Transmitter Installation
iConnect Installation Manual
118
Warning: Fire, explosion and severe burn hazard!
Do not recharge, disassemble or heat above 212°F (100°C)
Current Consumption: 25mA (transmission) 10µA (standby)
RFI Immunity: 40V/m
Cable Length: 2.4m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 2.5"H x 1.18"W x 0.9"D (65 x 30 x 25mm)
EL-2611 Keyfob
Antenna: Built-in Whip
Current Consumption:
16mA (transmission),
0µA (standby)
Power: Non-replaceable battery
RFI Immunity: 40V/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 2.36"H x 1.57"W x 0.59"D (60 x 40 x 15mm)
EL-2714 keyfob
Antenna: Printed on PCB
Power: 3V Lithium Battery
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: ø1.77" X 0.51"H (45ø x 13mm)
EL-2724 Wireless Terminal
Antenna: Printed on PCB
Frequency: 868.35MHz, 433.92MHz or 418MHz FM
Current Consumption: 55mA (transmission) 25mA (standby)
Power: 9VDC (supplied 230V/9V Adaptor)
Battery backup by 4x1.2V 1600mAh NiMH batteries
RFI Immunity: 40uV/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 5.1"H x 4.3"W x 1.1"D (130 x 110 x 28mm)
EL-2640 Wireless Keypad
Antenna: Printed on PCB
Current Consumption: 25mA (transmission)3µA (standby)
Power: 9V Alkaline Battery
RFI Immunity: 40V/m
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 5.0"H x 1.9"W x 1.1"D (128 x 49 x 27mm)
EL-2635 Repeater
Frequency: 868.35MHz, 433.92MHz or 418MHz FM
Antenna: External Whip
Operating Voltage: 9VAC (No. 1332) or 12VDC
Backup Battery: 6V/850mAh (ELPN BT5757)
(5 x 1.2V Ni-MH rechargeable cells, size AAAL, BT2635)
Current Consumption: 100mA max. (during transmission)
Number of Transmitters: 32 max.
Tamper Protection: Front Cover (N.C.)
Operating Temperature: 32 to 140°F (0 to 60°C)
Dimensions: 4.29"H X 4.84"W X 1.1"D (123 x 109 x 27mm)
Lithium Batteries
Fire, explosion and severe burn hazard!
When handling lithium batteries follow the listed precautions:
• Do not recharge.
• Do not deform or disassemble.
• Do not heat above 100°C or incinerate.
Due to the occurrence of voltage delay in lithium batteries that
have been in storage, the batteries may initially appear to be
dead. In this case, leave the unit in Test mode or Radio mode
for a few minutes until the battery voltage level is stabilized.
!
