ELTEX MES23xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 127
encrypted snmp-server
communitycommunity[ro|rw|
su][ipv4_address |
ipv6_address |ipv6z_address][
mask mask
|prefixprefix_length]][viewvie
w_name]
group_name: (1..30)
characters
- mask - IPv4 address mask that defines source address bits
to be compared to the specified IP address;
- prefix_length - number of bits that comprise the IPv4
address prefix;
- group_name - specify the name of the group, which should
be previously defined by the snmp-server group command.
Specify objects available to the community.
encrypted snmp-server
communitygroupcommunity
group_name[ipv4_address
|ipv6_address |ipv6z_address]
[maskmask|prefixprefix_lengt
h]
no snmp-server community
community [ipv4_address |
ipv6_address | ipv6z_address]
Remove community string parameters.
no encrypted snmp-server
communitycommunity[ipv4_a
ddress | ipv6_address
|ipv6z_address]
snmp-server view view_name
OID {included | excluded}
view_name: (1..30)
characters
Create or edit the SNMP view rule, the rule that allows or
prohibits the access by the browsing server to OID.
- OID - MIB object identifier represented as an ASN.1 tree
(string type 1.3.6.2.4, may include reserved words, e.g.
system, dod). The character ‘*’ can be used to specify a sub-
tree family: 1.3.*.2);
- include - OID is included in the browsing rule;
- exclude - OID is excluded from the browsing rule.
no snmp-server view
viewname [OID]
Remove the view rule for SNMP.
snmp-server group
group_name {v1 | v2 | v3
{noauth | auth | priv} [notify
notify_view]} [read read_view]
[write write_view]
group_name: (1..30)
characters
notify_view: (1..32)
characters
read_view: (1..32)
characters;
write_view: (1..32)
characters
Create an SNMP group or mapping table between SNMP
users and SNMP view rules.
- v1, v2, v3 – SNMP v1, v2, v3 security model;
- noauth, auth, priv – authentication type for SNMP v3
(noauth – w/o authentication, auth – authentication w/o
encryption, priv – authentication with encryption);
- notify_view - the name of the view rule that can specify the
‘inform’ and ‘trap’ SNMP agent messages;
- read_view - the name of the view rule that is only allowed
to read the SNMP agent of the switch;
- write_view - the name of the view rule that is allowed to
enter data and to configure the content of the SNMP agent
of the switch.
no snmp-server group
groupname {v1 | v2 | v3
[noauth | auth | priv]}
Remove an SNMP group.
snmp-server user user_name
group_name {v1 | v2c |v3
[remote {ip_address | host}]}
user_name: (1..20)
characters
group_name: (1..30)
characters
Create an SNMPv3 user.
- user_name – user name;
- grou_pname – group name.
no snmp-server user
user_name {v1 | v2c |v3
[remote {ip_address | host}]}
Remove an SNMPv3 user.
snmp-server filter filter_name
OID {included | excluded}
filter-name: (1..30)
characters
Create or edit an SNMP filter rule that filters ‘inform’ and
‘trap’ messages sent to the SNMP server.
- filter_name - SNMP filter name;
- OID - MIB object identifier represented as an ASN.1 tree
(string type 1.3.6.2.4, may include reserved words, e.g.
system, dod. The character ‘*’ can be used to specify a sub-
tree family: 1.3.*.2);
- include - OID is included in the filtering rule;
- exclude - OID is excluded from the filtering rule.
no snmp-server filter
filter_name [OID]
Remove an SNMP filter rule.
