MES53xx, MES33xx, MES23xx Ethernet Switch Series 184
priority-queue out

number_of_queues
number-of-queues: (0..8)
The default algorithm for
queue processing is “strict
priority”.
Set the number of priority queues.
The WRR weight will be ignored for a priority queue.
If N is not 0, then N highest queues will be
considered as priority queues (WRR will be ignored).
Example:
0: all queues are equal;
1: 7 lowest queues will be used in WRR, the 8th one will not;
2: 6 lowest queues will be considered in WRR, the 7th and
the 8th ones will not.
no priority-queue out

Set the default value.
qos wrr-queue wrtd
WRTD is disabled by
default.
Enable WRTD.
The changes will take effect after the device is
restarted.
no qos wrr-queue wrtd
Disable WRTD.
qos map policed-dscp
dscp_list to
dscp_mark_down
dscp-list: (0..63)
dscp-mark-down: (0..63)
The table of repeated
marking is empty by
default, i.e. DSCP values
remain the same for all
ingress packets.
Populate the table of DSCP remarking. Set new DSCP value for
ingress packets with specified DSCPs.
- dscp_list - define up to 8 DSCP values separated by spaces.
- dscp_mark_down - define a new DSCP value.
Applicable only for the QoS advanced mode.
no qos map policed-dscp
[dscp_list]
Set the default value.
qos map dscp-queue
dscp_list to queue_id
dscp-list: (0..63)
queue-id: (1..8)
Default values:
DSCP: (0 – 7), queue 1
DSCP: (8 - 15), queue 2
DSCP: (16 - 23), queue 3
DSCP: (24 - 31), queue 4
DSCP: (32 - 39), queue 5
DSCP: (40 - 47), queue 6
DSCP: (48 - 55), queue 7
DSCP: (56 - 63), queue 8
Set correspondence between DSCPs of ingress packets and
queues.
- dscp_list - define up to 8 DSCP values separated by spaces.
no qos map dscp-queue
[dscp_list]
Set the default values.
qos trust {cos|dscp |

-/cos
Set the switch trusted mode in the QoS basic mode (CoS or
DSCP).
- cos - sets CoS classification of ingress packets. The default
CoS value is used for untagged packets.
- dscp - sets DSCP classification of ingress packets.
- cos-dscp - sets classification of ingress IP packets by DSCP
and non-IP packets by CoS.
Applicable for the qos basic mode only.
no qos trust
Set the default values.
qos dscp-mutation
-
Apply the table of DSCP changes to the set of DSCP-trusted
ports. The table of changes allows DSCP values of IP packets to
be reset to new values.
The table of DSCP changes can be used only for
ingress traffic on trusted ports.
Applicable for the qos basic mode only.
no qos dscp-mutation
Disable the use of the DSCP changes.
qos map dscp-mutation
in_dscp to out_dscp
in-dscp: (0..63);
out-dscp: (0..63)
The table of changes is
empty by default, i.e. DSCP
values remain the same for
all ingress packets.
Populate the table of DSCP remarking. Set new DSCP values
for ingress packets with specified DSCPs.
- in-dscp - define up to 8 DSCP values separated by spaces.
- out-dscp - define up to 8 DSCP values separated by spaces.
Applicable for the qos basic mode only.
no qos map dscp-mutation
[in_dscp]
-
Set the default values.
