MES53xx, MES33xx, MES23xx Ethernet Switch Series 185
rate-limit vlan vlan_id rate
burst
vlan_id: (1..4094);
rate: (3..57982058) kbps;
burst: (3000..19173960)
bytes/128 kb
Set a rate limiting for the specified VLAN.
- vlan_id - VLAN number;
- rate - average traffic rate (CIR);
- burst - committed burst size in bytes.
no rate-limit vlan vlan_id
Remove the rate limiting.
Traffic classification criteria configuration mode commands
Command line prompt of the traffic classification criteria configuration mode is as follows:
console# configure
console(config)# class-mapclass-map-name[match-all | match-any]
console(config-cmap)#
Table 5.213. - Traffic classification criteria configuration mode commands
Command
Value/Default value
Action
match access-group
acl_name
acl_name: (1..32)
characters
Add a traffic classification criterion. Specify traffic filtering
rules according to the classification ACL.
Applicable only for the QoS advanced mode.
no match access-group
acl_name
Remove a traffic classification criterion.
Traffic classification strategy configuration mode commands
Command line prompt of the traffic classification strategy configuration mode is as follows:
console# configure
console(config)# policy-map policy-map-name
console(config-pmap)#
Table 5.214. Commands for traffic classification strategy edit mode
Command
Value/Default value
Action
class class_map_name
[access-group acl_name]
class_map_name: (1..32)
characters
acl_name: (1..32)
characters
Define a traffic classification rule and enter the policy-map
class configuration mode.
- acl_name - define traffic filtering rules according to the
classification ACL. The optional 'access-group' parameter is
mandatory for creating a new classification rule.
In order to use the policy-map strategy configuration
for an interface, use the service-policy command in
the interface configuration mode.
Applicable only for the QoS advanced mode.
no class class_map_name
Remove a class-map traffic classification rule from the policy-
map strategy.
Classification rule configuration mode commands
Command line prompt in the classification rules configuration mode is as follows:
console# configure
console(config)# policy-map policy-map-name
console(config-pmap)# class class-map-name [access-group acl-name]
console(config-pmap-c)#
Table 5.215. Commands of the classification rule configuration mode
Command
Value/Default value
Action
trust
By default, the trusted
mode is not set.
Defines the trusted mode for a certain type of traffic as per
global trusted mode.
no trust
Set the default value.
