ELTEX MES23xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 186
set {dscp new_dscp | queue
queue_id | cos new_cos}
new_dscp: (0..63);
queue_id: (1..8);
new_cos: (0..7)
Set new values for an IP packet.

for the same policy-map strategy.
The policy-
commands or have an ACL classification are assigned
only to outgoing interfaces.
Applicable only for the QoS advanced mode.
no set
Delete new values of an IP packet.
police committed_rate_kbps
committed_burst_byte
[exceed-action {drop |
policed-dscp-transmit}]
committed_rate_kbps:
(3..12582912) kbps;
committed_burst_byte:
(3000..19173960) bytes
aggregate_policer_name:
(1..32) characters
Limit bandwidth to a specific transfer rate.
The “marked bucket” algorithm is used to reduce the
bandwidth. The algorithm decides whether to send or drop
the packet. the rate of token arrival to the "bucket" (CIR) and
the "bucket" size (CBS).
- committed_rate_kbps - the average traffic rate. This rate is
assured for data transmission;
- committed_burst_byte - committed burst size in bytes;
- drop - a packet will be dropped if the bucket is full;
- policed-dscp-transmit - if the bucket is full, the DSCP value
will be overwritten.
Applicable only for the QoS advanced mode.
police agregate
aggregate_policer_name
Assigns a configuration template to a traffic classification rule
that limits bandwidth while guaranteeing a certain data
transfer rate.
Applicable only for the QoS advanced mode.
no police
Remove a channel rate configuration template from the traffic
classification rule.
Ethernet or port group interface configuration mode commands
Command line prompt in the Ethernet or port group interface configuration mode is as follows:
console(config-if)#
Table 5.216. Ethernet or port group interface configuration mode commands.
Command
Value/Default value
Action
service-policy {input |
output} policy_map_name
policy_map_name: (1..32)
characters
Assign a traffic classification strategy to an interface.
no service-policy {input |
output}
Remove a traffic classification strategy from an interface.
traffic-shape
committed_rate
[committed_burst]
committed_rate:
(64..1000000) kbps;
committed_burst:
(4096..16762902) bytes
Set a traffic shaping for an interface.
- committed_rate - average traffic rate, kbps;
- committed_burst - committed burst size in bytes.
no traffic-shape
Remove a traffic shaping for an interface.
traffic-shape queue
queue_id committed_rate
[committed_burst]
queue-id: (0..8);
committed-rate:
(36..1000000) kbps;
committed-burst:
(4096..16,769,020) bytes
Limit traffic rate for the transmit queue through the interface.
- committed_rate - average traffic rate, kbps;
- committed_burst - committed burst size in bytes.
no traffic-shape queue
queue_id
Remove a traffic rate limit for the transmit queue through the
interface.
qos trust
-/enabled
Enable the basic QoS for the interface.
Applicable for the qos basic mode only.
no qos trust
Disable the basic QoS for the interface.
rate-limit rate [burst burst]
rate: (100..10000000)
kbps;
burst: (3000..19173960)
bytes/128 kb
Set the rate limiting.
no rate-limit
Remove the rate limiting.
qos cos default_cos
default_cos: (0..7)/0
Set CoS as the default value for a port to (the CoS value that is
used for all untagged traffic on the interface).
no qos cos
Set the default value.
