MES53xx, MES33xx, MES23xx Ethernet Switch Series 67
switchport general acceptableframe-type {untagged-

-/accept all frame
types
Accept only specific frame type on the
interface:
- untagged-only – only untagged;
- tagged-only - tagged only;
- all – all frames.
switchport trunk allowed vlan add vlan_list
vlan_list: (2..4094,
all)
Add a VLAN list for the interface.
- vlan_list - list of VLAN IDs. To define a
VLAN number range, enter values
separated by commas or enter the starting
and ending values separated by a hyphen ’-
’.
switchport trunk allowed vlan remove vlan_list
Remove the VLAN list for the interface.
switchport trunk native vlan vlan_id
vlan_id:
(1..4094)/1
Add the VLAN ID as Default VLAN for this
interface. All untagged traffic coming to
this port will be directed to this VLAN.
- vlan_id - VLAN ID.
no switchport trunk native vlan
Set the default value.
switchport general allowed vlan add vlan_list [tagged
| untagged]
vlan_list: (2..4094,
all)
Add a VLAN list for the interface.
- tagged - the port will transmit tagged
packets for the VLAN;
- untagged - the port will transmit
untagged packets for the VLAN;
- vlan_list - list of VLAN IDs. To define a
VLAN number range, enter values
separated by commas or enter the starting
and ending values separated by a hyphen ’-
’.
switchport general allowed vlan remove vlan_list
Remove the VLAN list for the interface.
switchport general pvid vlan_id
vlan_id:(1..4094)/
1 - if default VLAN
is set
Add a port VLAN identifier (PVID) for the
main interface.
- vlan_id – VLAN port ID.
no switchport general pvid
Set the default value.
switc
-/filter is enabled
Disable filtering of ingress packets on the
main interface based on their assigned
VLAN ID.

Enable filtering of ingress packets on the
main interface based on their assigned
VLAN ID.
If filtering is enabled, and the packet is not
in VLAN group with the assigned VLAN ID,
this packet will be dropped.
-type {tagged-

-/accept all frame
types
Accept only specific frame type on the
main interface:
- tagged-only - tagged only;
- untagged-only – only untagged;
- all – all frames.
no switchport general acceptable-frame-type
Accept all frame types on the main
interface.
switchport general map protocols-group group vlan
vlan_id
vlan_id:(1..4094);
group: (1..
2147483647).
Set the classification rule for the main
interface based on the protocol tethering.
- group – group number ID;
- vlan_id - VLAN ID.
no switchport general map protocols-group group
Remove a classification rule.
group vlan vlan_id
vlan_id: (1..4094);
group:
(1..2147483647).
Set a classification rule for the main
interface based on MAC address tethering.
- group – group number ID;
- vlan_id - VLAN ID.
no switchport general map macs-group group
Remove a classification rule.
switchport general map protocols-group group vlan
vlan_id
vlan_id: (1..4094)
group: (1..
2147483647)
Set a classification rule for the main
interface based on protocol tethering.
- group – group number ID;
