MES53xx, MES33xx, MES23xx Ethernet Switch Series 68
- vlan_id - VLAN ID.
no switchport general map protocols-group group
Remove a classification rule.
switchport dot1q ethertype egress stag ethertype
ethertype:(1..ffff)
(hex)
Substitute TPID (Tag Protocol ID) in 802.1q
VLAN tags of packets outgoing from the
interface.
For available Ethetype values, see
Appendix c. Supported Ethertype
values.
switchport dot1q ethertype ingress stag add ethertype
ethertype:(1..ffff)
(hex)
Add TPID in table of VLAN classifiers.
For available Ethetype values, see
Appendix c. Supported Ethertype values.
switchportdot1qethertypeingressstagremoveethertype
Delete TPID from table of VLAN classifiers.
switchport customer vlan vlan_id
vlan_id:
(1..4094)/1
Add a VLAN for the user interface.
- vlan_id - VLAN ID.
no switchport customer vlan
Set the default value.
switchport customer multicast-tv vlan add vlan_list
vlan_list: (2..4094,
all).
Enable the receipt of multicast traffic from
the specified VLANs (other than the user
interface VLAN) on the interface together
with other port users that receive multicast
traffic from these VLANs.
- vlan_list - list of VLAN IDs. To define a
VLAN number range, enter values
separated by commas or enter the starting
and ending values separated by a hyphen
’-’.
switchport customer multicast-tv vlan remove
vlan_list
Disable the receipt of multicast traffic for
the interface.
switchport forbidden vlan add vlan_list
vlan_list: (2..4094,
all)/all VLAN are
enabled for this
port
Deny adding specified VLANs for this port.
- vlan_list - list of VLAN IDs. To define a
VLAN number range, enter values
separated by commas or enter the starting
and ending values separated by a hyphen
’-’.
switchport forbidden vlan remove vlan_list
Allow adding the selected VLANs for this
port.

By default ,
membership in the
default VLAN is
enabled.
Deny adding the default VLAN for this port.
no switchport forbidden default-vlan
Set the default value.
switchport protected-port
-
Put the port in isolation mode within the
port group.

Restore the default value.
switchport protected {gigabitethernet gi_port |
tengigabitethernet te_port | fortygigabitethernet
fo_port | port-channel group}
gi_port:
(1..8/0/1..48);
te_port:
(1..8/0/1..24);
fo_port:
(1..8/0/1..4);
group: (1..16)
By default, routing
is based on the
database of
learned MAC
addresses (FDB).
Put the port into Private VLAN Edge mode.
Disable routing based on the database of
learned MAC addresses (FDB) and forward
all unicast, multicast and broadcast traffic
to the uplink port.
no switchport protected
Enable routing based on the database of
learned MAC addresses (FDB).
switchport default-vlan tagged
-
Specify the port as a tagging port in the
default VLAN.
no switchport default-vlan tagged
Set the default value.
Privileged EXEC mode commands
Command line prompt in the Privileged EXEC mode is as follows:
