Faults
24
5.
The rectifier could also
be fault
y
Checking the high fr
equency generator
DANGER
Mortal danger from ele
ctric shock
Exposed power contacts
- High Vo
ltage
Never try to measu
re the voltage here
!
Due to high voltage
in the range of 7000 V
olts (amplitude), th
ere should be no m
easurem
ent on
the rectifier under po
wer. If no spare rectif
ier available to exchan
ge, then test b
y using a scope
according to the follo
wing drawing.
Fig.
16
:
Rectifier
about
4000 Ω
Rectifier
220 VAC
Adjustable
transformer
220 VAC
Insulating
transformer
23
25
