Description
21
Position
Component
Description
1
Cooling water connection
This is the outlet. Heated water flows out of the device
to the heat exchanger in order to be cooled down.
2
Cooling water connection
This is the inlet. Cooled water flows from the heat
exchanger flows into the device in order to cool the
furnace.
3
Vacuum cleaner connection
Provided that the device is equipped with a cleaner,
this is where the vacuum cleaner shall be connected.
4
Device fuse, power section
The power section of the device is protected with this
double fuse block.
5
Device fuse, control part
The control part of the device is protected with this
single fuse block.
6
Power connection line
This is the power connection line of the device.
7
USB port
The USB port is used for the communication with the
PC.
8
Supply connection of the heat
exchanger
This is where the power supply for the Eltra heat
exchanger is connected.
9
Connection of the compressed air
This is where the compressed air supply for the
pneumatics is connected.
10
Connection of the helium carrier
gas
This is where the helium carrier gas is connected
(only ON-p and ONH-p).
11
Connection of the argon carrier gas
This is where the argon carrier gas is connected (only
ON-p and ONH-p).
12
Connection of the nitrogen carrier
gas
This is where the nitrogen carrier gas is connected
(only ON-p and ONH-p).
13
Connection of the exhaust gas
This is where an extraction system should be
connected in order to discharge the combustion gases
in a safe manner.
