Risk of injury
Moving parts
− The lock moves according to user input. Hands in the area of the upper
furnace lock can be crushed when the lock closes.
• Never reach into a moving lock.
• Turn the main switch of the analyser to position 1 or 0.
• Press the button “furnace cleaning” on the tab “Analyser status” of the software.
• Loosen the fastening screws of the upper furnace cover and remove it upwards.
• Loosen the two nuts on the furnace lock assembly
.
• Carefully remove the furnace lock assembly upwards and place the assembly
backwards on the analyser.
Please pay attention to the slidingly mounted locking element.
