Before replacing the filling of the dust trap, please see Section (4) in „10.5
Filling of reagent tubes“) and proceed as follows:
1. Turn the main switch of the analyser to switch position 1.
2. Before removing the reagent tube, please see „Removing and
installing of reagent tubes“.
3. Remove the contaminated glass wool from the reagent tube by
means of a tweezer.
4. Dispose of the material in accordance with local rules and
regulations.
5. Remove the sinter filter by means of the assembly tool (Item
number 27000-3158)
6. Pre-clean the sinter filter with a paper towel and then place it in an
ultrasonic bath.
7. Make sure the sinter filter is completely dry or replace it with a dry
one.
8. Use a cloth in order to clean the reagent tube from dirt and grease
residues.
9. Please make sure that the reagent tube is undamaged.
10. In the event that it is damaged or too much contaminated, use a
new reagent tube (Item number 11064-3001).
11. Fill the reagent tube with 5 cm glass wool (Item number 90331).
12. Push the cleaned and dried sinter filter with the hollow side up to
the stop on the mandrel of the assembly tool.
13. Put the two O-rings over the sinter filter and push them also up to
the stop against the assembly tool
.
14. Push the sinter filter into the reagent tube up to the marking
.
15. Insert the filled reagent tube in such a way that the glass wool
points towards the furnace (please see „Removing and installing of
reagent tubes“).
The filling of the reagent tube has now been replaced.
