Spare parts
81
11.1.3 Lower furnace
Position
Name
Item number
Quantity
1
Lower electrode,
graphite tip
31360
1
2
Lower electrode
holder with screws
31365-8000
1
3
O-ring 47,2x5,7
70405
1
High vacuum
grease
92610
1
4
Countersunk screw
M3x12
08.643.0185
4
5
Lower furnace
cover
27000-3220
1
6
Pneumatic cylinder
furnace
66200-0184
1
Fig. 9: Furnace, Front view 1
1
2
3
411
5
6
