Technical data
44
7 Technical data
7.1 Technical data ELEMENTRAC ONH-p 2
The following table lists the technical data for the device in 3-phase configuration:
Definition
Description
Value
Dimensions and weight
Width
56 cm
Depth
64 cm
Height
78 cm
Weight
approx. 165 kg
Electrical data
Power supply
400 V AC ± 10 %, 3 phases, ground and
neutral conductor.
Frequency
50/60 Hz
Power consumption
L1=32A, L2=30A, L3=0A
Mains connection
Three-phase plug
(3L+N+PE, 6h 32A according to IEC 60309)
Safety
Protection class
I
Overvoltage category
II
Degree of pollution
2
Type of environment
Inside
Max. ambient altitude
2000 m
Ambient temperature
+5 to +35°C
Ambient humidity
< 80 % at 31°C non-condensing
Protection class
IP20
Carrier gas
Type
Nitrogen
Purity
Min. 99,995 %
Pressure
2 to 4 bar (30 to 60 psi)
Connection
Polyamide hose 6/4 mm (adapter with G¼"
internal thread, included in the scope of
delivery)
Carrier gas
Type
Helium
Purity
Min. 99,995 %
Pressure
2 to 4 bar (30 to 60 psi)
Connection
Polyamide hose 6/4 mm (adapter with G¼"
internal thread, included in the scope of
delivery)
Carrier gas
Type
Argon
Purity
Min. 99,995 %
Pressure
2 to 4 bar (30 to 60 psi)
