Unpack your system
9
Unpack your system
Unpacking the shipping boxes
You might have received your system already racked and cabled in an EMC cabinet or in a
mini-rack to be unpacked and installed into your own cabinet.
If your system was shipped fully assembled and cabled in an EMC cabinet:
1. Follow the unpacking instructions on the outside of the box.
2. Skip all sections up to “Cable your system” on page 27 of this installation guide. In “Cable
your system” on page 27 verify your cabling.
If your system was shipped in a mini rack:
1. Verify that you have received all of the system’s components, including cables and bezels.
Table 3 lists the shipping contents.
Table 3 Example shipping contents
Components Accessories
❏
One or two blade enclosures • Mounting screws
• Bezels and bezel keys
• Management cables
• Power cables
•Fibre cables
❏
One or two Control Stations (CSs) • Mounting screws
• Bezels and bezel keys
•Extension cables
•IPMI cable
Note: IPMI cable is only available with a second CS.
• Management cable
•Power cable
❏
Disk processor enclosure (DPE) • Mounting screws
• Bezel and bezel keys
•Power cable
❏
Standby power supply (SPS) • Mounting screws
• Bezel
• Management cable
•Power cable
