EMC2 VNX5500 - Installing VNX5500 Disk Processor Enclosure

Installing components 19
Installing disk processor enclosure
There are two types of disk processor enclosures (DPEs). Your disk processor enclosure can be
either a 3U, 25 2.5” drive DPE or a 3U, 15 3.5” drive DPE as shown in Figure 8. It goes into the
next available space in the ganged rails.
Figure 8 Types of DPEs
3U, 15 3.5” drive Disk processor enclosure front
1 X4
2
3
4
5
6Gb
SAS
8Gb
bre
0 X4
6Gb SAS
A
2
3
4
5
6Gb
SAS
8Gb
bre
0 X4
6Gb SAS
B
SP B
SP A
1 X4
24
3U, 25 2.5” drive Disk processor enclosure front
0
12345678910 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0
3U, Disk processor enclosure rear
0
14
VNX-000188
