Verifying system status
While your system is powering up, you will see green, blue, and amber activity lights blink. You
can verify that your system powered up completely after 10-15 minutes.
Table 4 lists the LEDs that you need to focus on to ensure that the system is powered up correctly.
The
VNX5500 Hardware Information Guide provides more information on all the LEDs.
Table 4 System status LEDs
Component LED Location State/color
Blade Enclosure Power Front On/blue or green
Blade power
supply
Power Front On/green
Fault Front Off
Blade CPU A
and B
Power Front On/green
Fault Front Off
Control Station System status
System power
Front
Front
On/green
On/green
Disk processor
enclosure
Power Front On/blue or green
Fault Front Off
Disk processor
power supply
Power
Fault
Rear of the unit (SP A
and SP B)
Rear of the unit (SP A
and SP B)
On/green
Blinking/amber (booting up)
Off
Disk processor
SPA and B
Power
Fault/Status
Rear of the unit (SP A
and SP B)
Rear of the unit (SP A
and SP B)
On/green
Off
Standby power
supply
— Rear The LEDs on the back of the SPS will
flash until fully powered.
