VNX File configuration worksheet
With your network administrator, determine the IP addresses and network parameters you plan to
use with the storage system, and record the information on the following worksheet. You must
have this information to set up and initialize the system.
You manage the storage system through a dedicated LAN port on each storage processor. These
ports must share a subnet with the host you use to initialize the system. After initialization, any
host on the same network and with a supported browser can manage the system through the
management ports.
Record network information for your system on the worksheets on the next pages. Your network
administrator should provide most of this information. For more information, refer to your
configuration planning guide.
To download the latest version of the VNX Installation Assistant for File/Unified, go to the
https://support.EMC.com and select Support. Search for VNX Installation Assistant.
IMPORTANT
The VNX Installation Assistant for File/Unified auto-discovers and pre-populates certain values
based on the system and network environment of your Windows client. Ensure you verify and fill
these values in to the Value column by recording the results of the auto-discovery.
Table 6 Control Station public LAN settings
Field Value Comments
CS0 Primary hostname
CS1 Secondary hostname
CS0 Primary IP address If you want to configure IPv6 addresses for
the Control Station address, use the VNX
Installation Assistant for File/Unified for
the initial installation, and then refer to the
Configuring and Managing Networking on
VNX
technical module and the EMC VNX
Command Line Interface Reference for File
to complete the IPv6 additions.
CS1 Secondary IP address
Netmask Auto-discovered (required). Enter this
information into the Value column of this
table.
Gateway Auto-discovered (required). Enter this
information into the Value column of this
table.
DNS domain Auto-discovered (required). Enter this
information into the Value column of this
table.
