SEP 2005 MODEL 1000
DESCRIPTION
1-18
Note that the average concentration of each component will also be calculated when data averaging
is requested.
Component concentrations may be input through analog inputs 1 - 4 or may be fixed. If a fixed
value is used, the calibration for that component is the mole % that will be used for all analyses.
Concentration Calculations with Normalization
Where:
n
CONCN = Normalized concentration of component “n” in percent of total gas
concentration.
n
CONC = Non-normalized concentration of component “n” in mole %
i
CONC = Non-normalized concentration (in mole %) from each of the “k”
components to be grouped into this normalization
k = Number of components to be included in the normalization
For additional information about other calculations that are performed by the GC Controller
and software, see the MON2000 Software for Gas Chromatographs User Manual (P/N 3-
9000-522).
