SEP 2005 MODEL 1000
INSTALLATION AND SETUP
3-18
3.2.5 Optional Tools and Components
1
Observe Precautions and Warnings
2
Plan Site Location
3
Obtain Supplies and Tools
»
4
Install Analyzer Wiring
Observe the following checklist of tools and components you may need for installing and using
the GC System:
(1) For operation in a nonhazardous area only: Printer and printer paper.
(2) For operation in a nonhazardous area only: An IBM-compatible PC and a “straight-
through” serial cable connection between the external DB-9 (female) serial ports of the GC
Controller and a serial port of the PC. (For details, see Section 3.4.3.)
SERIOUS PERSONAL INJURY OR DEATH POSSIBLE
Do not operate a PC or printer in a hazardous environment.
Failure to observe all safety precautions could result in serious injury or death.
If you are working in a hazardous area and need to perform routine operations, use the optional
keyboard and LCD that are built into the purged GC Controller (see Section 4 this manual). To
make more significant program changes, however, use a remotely connected PC and the software
program MON2000. (See the MON2000 Software for Gas Chromatographs User Manual, P/N
3-9000-522, for instructions on operating the PC software, MON2000.)
(a) PC Specifications: Refer to Section 1.4.1, Minimum PC Requirements.
